Physical Feature
Q: What are the sizes of the tag?
A: There are three sizes: 2.6×2.6×0.8mm; 3.0×3.0×0.8mm; 4.0×4.0×1.0mm
Q: What frequency can these tag support?
A: According to the shape of the external coupled antenna, it can adapt to the full frequency of 860MHz ~ 960MHz.
Q: What chips does the tag support?
A: Supports all ISO18000-6C chips.
Q: Is the tag high temperature resistant?
A: -196℃/>2000h, 125℃/>1000h, 260℃/5min.
Q: Is the label waterproof?
A: Protection grade IP67.
Q: Are these tags divided into both sides?
A: There is no distinction between positive and negative.
Q: Can these tags be with adhesive?
A: Tag without adhesive.
Q: In what form is the tag shipped?
A: Single bulk static bag packaging or braiding. -
Application
Q: Can tags be used on metal?
A: The metal material itself can be used to change it into a coupled antenna.
Q: Can these tags be used on metal?
A: The metal itself can be used as a coupled antenna.
Q: Can these tags be embedded into metal?
A: Can't be embedded in the metal.
Q: How to place theses tags on metal materials?
A: Directly place the tag upright on the metal edge or open a long slit on the metal and place the tag flat on the slit (the placement position needs to be adjusted according to the shape of the metal) -
Performance
Q: What is the read distance of the extended antenna without coupling?
A: It can be identified at close range without using the coupling extension antenna. The identification distance will vary according to the model of the reader, and the identification distance is within 0.5m.
Q: What is the read distance of the extended antenna using coupling?
A: Depending on the length and shape of the coupled antenna, the recognition distance can be extended to several meters. -
Other
Q: Can the tag size be customized?
A: The size cannot be customized.
Q: Can these tag surface be printed?
A: The surface can be printed with laser UV codes within 6 characters.
Q: What's the MOQ of this tag?
A: The MOQ is 10K.
Q: How long is the general delivery date?
A: 6-8 weeks for less than 500K, 8-10 weeks for more than 500K
Product: Super Mini UHF Tag
Dimension: 2.6*2.6*0.8mm, 4*4*1mm
RF Protocol: EPC Class 1 Gen 2, ISO 18000-6C
Key Application: On-metal, On-liquid, RF Booster, Asset Sticker Applications
MOQ: 100PCS
Overview
Magic Series is an industrial-grade passive UHF TAG with super tiny dimension, features high temperature resistance, corrosion resistance, waterproof IP67 level, metal resistance, liquid friendly and other highlights.
Either boost antenna, externally mounted or directly placed on metal, RFID applications in liquid environment or even asset sticker application, can be used widely and developed in infinite way!
• With built-in antenna design, readable & recognized directly by
reader or handheld device
• Wide frequency range 860~940M meets variable RFID/IOT
applications
• Super-mini sized design allows wide applications with smallsized products and targets
• Passive UHF chip, EPC Class1 Gen2, ISO18000-6
• Extended antenna will increase R/W distance, up to 15M and - 20dBm
Performance
Voyantic testing curve after connecting the extension enhance antenna in external.
|
Model |
26266P1 |
2626U81 |
4040R61 |
40406P1 |
|
Chip |
Impinj Monza R6P |
NXP Ucode8 |
Impinj Monza R6 |
Impinj Monza R6P |
|
Memory |
User 32 ~ 64 bits |
User 0 bit |
User 0 bit |
User 32 ~ 64 bits |
|
TID 48 bits |
TID 96 bits |
TID 48 bits |
TID 48 bits |
|
|
EPC 96 ~128 bits |
EPC 128 bits |
EPC 96 bits |
EPC 96 ~128 bits |
|
|
Dimension |
2.6 × 2.6 × 0.8 mm |
4.0 × 4.0 × 1.0 mm |
||
|
Protocol |
EPC Class 1 Gen 2 ISO 18000-6C |
|||
|
Frequency |
860 ~ 940 MHz |
|||
|
Working Temperature |
-40℃ ~ 85℃ |
|||
|
Heat-resistance |
260℃ / > 5 min |
|||
|
Cold Tolerance Ability |
-196℃ / > 2000 h |
|||
|
Mechanical Strength |
> 20 N |
|||
|
Antistatic Ability- ESD |
±10 KV (HBM) |
|||
|
Specification Optional |
SMT Pad |
|||
On PCBA
In Liquid
With Metal Tools
With Laundry Tags
