Providing first class RFID tags is our key and constant mission! Never compromise on quality!!
Quality doesn’t come from inspection, even we do 100% inspection for each item!
Quality comes from advanced design and strict control during manufacturing process!!
In order you know exactly performance of such product, we will show our lab testing to measure key parameters, including Resonance Frequency, Q Value, Read/Write Distance, Protocol, UID etc.
Chip: Mifare Ultralight C
Mainly, we will use following professional instruments to measure key functionality parameters.
Network Analyzer
Model: Anritsu MS4630B
Frequency Range: 10HZ-300MHz
Calibration certificate authorization
Frequency
Range: 10 HZ to 300MHZ
Resolotion: 0.01HZ
Accurancy(standard)
Aging rate:≤1×10-6/day(15 minutes after power-on)
Temperature characteristics:≤±5×10-6(0 to +50℃)
Accurancy(Option 13: High stability refrence oscillator)
Aging rate:≤1×10-8/day(15 minutes after power-on)
Temperature characteristics:≤±5×10-8(0 to +50℃)
Main measurement parameter: Resonance Frequency, Q Value
| Sample 1 | Sample 2 | Sample 3 | Sample 4 | Sample 5 |
| Resonance Frequency | 13.31MHz | 13.34MHz | 13.34MHz | 13.31MHz | 13.31MHz |
HF RFID Tag Tester
Model: FQ-5X-U
Frequency Range: 1-30MHz
Use this device to measure: RF Functionality, Resonance Frequency, Q Value, RF Protocol
Testing Results
| Sample 1 | Sample 2 | Sample 3 | Sample 4 | Sample 5 |
| Resonance Frequency | 13.62MHz | 13.58MHz | 13.63MHz | 13.50MHz | 13.61MHz |
| Q value | 20 | 24 | 25 | 13 | 27 |
| Protocol | ISO14443A | ISO14443A | ISO14443A | ISO14443A | ISO14443A |
| UID | 04 1E 4D 9A 98 3C 81 | 04 25 4D 9A 98 3C 81 | 04 12 4D 9A 98 3C 81 | 04 18 4D 9A 98 3C 81 | 04 24 4D 9A 98 3C 81 |
Handheld RFID Card/Tag Reader
Model………………………………………
Power: ……………………………………….
Support Protocol: ISO 14443/15693/NFC etc.
Use this reader to do RF function testing and reading distance measurement.
Testing Results
| Sample 1 | Sample 2 | Sample 3 | Sample 4 | Sample 5 |
| RF Functionality | Yes | Yes | Yes | Yes | Yes |
We are happy to optimize tag’s RF performance to match your R/W device and reach best results for your application!
Welcome to ask if you want to know more about this instrument =>
Biz@readfind-iot.com
NFC Interoperability in Automotive
E-Purse
Information Interaction
