Description

Specification

Material:	Silicone
Body Color:	Black, Blue, Red, Yellow, Pink, Green etc.
Available Chip:	LF, HF, UHF on request
Optional Service:	Color/logo/numbers printing, customized requirement, UID
Working Temperature:	-30℃～ 220℃
Standard Package:	100 pcs/pouch
Main Features:	Water proof, high temperature resistance, durable, eco-friendly
Application:	Water Parks, Theme Parks, Concerts/Festivals, Resorts, Clubs, Sporting Venues, etc.

Personalized Service

Graphics Laser Engragving

Laser Coloring

Fill Color

Graphics Colorful Printing

Epoxy

RFID vs Barcode Wristbands Comparison Table

Work flow

Application

RFID Silicone Wristband is a portable transponder It provides outstanding performance and durability in harsh environmental conditions.

E-Purse: Make trading easier

Transport: More personalized transit payments

Membership: Better membership management

Manufacturing View

Dyeing

Injection

Molding

Demould

Function Test

Laser

Package

Bagging

Encasement

Sealing

Ordering

-MOQ: 100 pcs.

-Lead Time for standard job: 1K 10 days, 10K 15 days, 50K 20 days, 100K & above ask sales. You will get response in 24 hours.

-Quotation: Ask our sales & service team Biz@readfind-iot.com

Quality Guarantee

Providing first class RFID tags is our key and constant mission! Never compromise on quality!!

Quality doesn’t come from inspection, even we do 100% inspection for each item!
Quality comes from advanced design and strict control during manufacturing process!!

In order you know exactly performance of such product, we will show our lab testing to measure key parameters, including Resonance Frequency, Q Value, Read/Write Distance, Protocol, UID etc.

Performance Test

Product: Silicon RFID wristband

Chip: S50

Model: RSW-KGD02

Dimension: 213*16*42mm

Performance Test

Mainly, we will use following professional instruments to measure key functionality parameters.

T8200PRO-G LF/HF Tag Tester

Testing Item:

1. Resonance frequency

2. Attenuation

3. Q factor

4. UID

Network Analyzer

Model: Anritsu MS4630B

Frequency Range: 10HZ-300MHz

Calibration certificate authorization

Frequency

Range: 10 HZ to 300MHZ
Resolotion: 0.01HZ
Accurancy(standard)
Aging rate:≤1×10-6/day(15 minutes after power-on)
Temperature characteristics:≤±5×10-6(0 to +50℃)
Accurancy(Option 13: High stability refrence oscillator)
Aging rate:≤1×10-8/day(15 minutes after power-on)
Temperature characteristics:≤±5×10-8(0 to +50℃)

Main measurement parameter: Resonance Frequency, Q Value

Testing Results

	Sample 1	Sample 2	Sample 3	Sample 4	Sample 5
Resonance Frequency	14.26MHz	14.49MHz	14.25MHz	14.53MHz	14.53MHz

HF RFID Tag Tester

Model: FQ-5X-U
Frequency Range: 1-30MHz
Use this device to measure: RF Functionality, Resonance Frequency, Q Value, RF Protocol
Testing Results

	Sample 1	Sample 2	Sample 3	Sample 4	Sample 5
Resonance Frequency	14.01MHz	14.28MHz	14.03MHz
Q value	22	23	21
Protocol	ISO14443A	ISO14443A
UID	44388F40	44458240

Handheld RFID Card/Tag Reader

Model………………………………………
Power: ……………………………………….
Support Protocol: ISO 14443/15693/NFC etc.
Use this reader to do RF function testing and reading distance measurement.
Testing Results

	Sample 1	Sample 2	Sample 3	Sample 4	Sample 5
RF Functionality	Yes	Yes	Yes	Yes	Yes
R/W distance-mm	<15mm	<15mm	<15mm	<15mm	<15mm

We are happy to optimize tag’s RF performance to match your R/W device and reach best results for your application!
Welcome to ask if you want to know more about this instrument =>Biz@readfind-iot.com

Quality Control

Quality Control During Manufacturing

— R&D process: Reliable technology for key component/part choose

Fill Oil

Epoxy

Pad Printing

Laser

Compare with other vendor, even outlooking is nearly same, but probably the heart of Silicon Wrist Band is different!! The embedded token tag is such heart!! Actually, so many know-hows lead the quite different reliability and quality! But most seller will not tell you!! Even they don’t care about it! But, we are not!

— Proper material used

FPC

PCB

Epoxy

Ceramic

— Trackable production

Molding

Injection

Encoding

Pad Printing

— 100% functionality and visual inspection

Material Hardness

Tensile Test

Appearance Instrumentation

Function Test

We’re happy to share you more details by offline, allow you know more as we can.

FAQ

General Information

Question	Answer
Can I get a quotation?	If you have a special request you can simply email us at contacts@rsmart.com.cn and we will be more then glad to help you out.
What is your minimum order quantity for wristbands?	100 pcs.
What’s the turnaround time?	We have the fastest turnaround time in the nation. Standard turnaround is 7 days production and 7 days shipping. The best part about our company is that we guarantee our delivery dates.
What sizes are available?	If you want a custom size then please call our sales team and they will advise you on how to place a special order.
Can I place my order online?	Yes, you can. Following are the ways you can place your order: 1. Online 2. On the phone +86 21 6432 6941 3. Via email contacts@rsmart.com.cn 4. Via Skype/whatsapp
I need to make a change to the order that I placed.	Contact with our sales team and they will try to make the change as long as the order is not in production.
How printing will appear on Tyvek/Plastic?	All Tyvek/Plastic bands the message is always left indent unless any special instruction is given.
I want custom rubber wristbands, Is your price lowest?	Our prices are ALWAYS the lowest in the market for wristbands. We can assure you that there will be no company in the market that will be able to provide a lower price and faster turnaround then our company.
Badge Holders/ID Reels Printing Extra Charges	Depending on the gradiation of colors and artwork complexities for overlapping colors, there might be additional cost which can be informed post proof made by factory.

About Artwork

Question	Answer
Can I put a logo or emblem on my bands?	Yes you can send your own logo to our sales.
Why the color of actual products is not exact same as the proof I approve?	The colors of the proof as shown are approximate and will differ on each computer monitor. We use PANTONE color number for mixing colors.
Can I use other font, not the regular font?	Yes, you can provide the font you want to print on the band.
Can I customize wristbands with a different color than the popular colors?	Yes you can use any color from the Pantone Card.

About Digital Proof

Question	Answer
Can I preview before I purchase?	We offer you free proof before you decide to purchase and a hassle free experience.
Will I be charged extra if want to change the proof before confirming the order?	No, you can make as many changes as you like.
I received my proof and I want to make a change. How can I do that?	Simply reply back to the email proof that you received and tell us the change you would like and we will revise the proof and send you a new proof.
How long does it take to get a digital proof?	It will take anywhere from 4-6 hours.
What is a digital proof?	A digital proof is a digital image of how your wristbands will look. We will show you a image before we start production. You can make as many changes as you like to the digital proof until you are satisfied.
How can I confirm to the proof I received?	Simply reply to the proof email stating that you confirm the proof layout and then we will start production.
